Topconnect API

Hello there! In this guide, you will find all the information required for integrating your platform with TopWallet and avail of its core functionalities.
We’ve tried to make the guide simple and easy to follow, with as much detail as possible and we have a wide array of api’s to select. If you have any questions, contact us at support@topconnect.io. We would love to help you out.
TopWallet provides a highly efficient solution to help organizations scale their payment disbursement and acceptance modules for both - conventional payments or digital assets.

Fast: We have optimized our solution for speed - You can go live in an afternoon and your customers can onboard in seconds.

High quality: In-house, world class AI models and a UI designed for low drop offs.

Flexible: Allows you to change branding, texts & workflows with zero code

Resilient: Our uptime has consistently been above 99.9%

Scalable: Capable of handling volume spikes as it is auto scalable

Secure: Annual 3rd party audits, VAPT, ISO certification, end to end data encryption

Additonally:

You can use the dashboard to access credentials or configure the solution as per your requirements. This dashboard also lets you view the application data and corresponding analytics.

We have engineered the SDK’s & dashboard to work together, so that you can finish your integration with just a few lines of code.

We have engineered the API's & dashboard to work together, so that you can finish your integration with just a few lines of code!

Authentication

All API requests must be signed with your API Key and Secret Key using HMAC-SHA256.

• Your API Key (ak_...) identifies your account and is sent with every request.
• Your Secret Key (sk_...) is used to compute the signature. Never send it in a request, and never put it in browser or mobile app code.
  All requests must use HTTPS. Requests over plain HTTP are rejected.

---

Required headers

Header	Description	Example
X-API-Key	Your API key	ak_test_51HxQ2EXAMPLEKEY
X-Timestamp	Current Unix time in seconds (UTC)	1760610000
X-Nonce	Random, unique string per request (16+ bytes, hex). Never reuse.	7c2f9e1a4b8d3c6e5f0a1b2c3d4e5f60
X-Signature	Lowercase hex HMAC-SHA256 signature (see below)	2b2b6750...0f58c1
Content-Type	application/json for requests with a body	application/json

Building the signature

Step 1: Hash the request body

Compute the SHA-256 hash of the exact raw body bytes you will send, as lowercase hex.
For requests with no body (e.g. POST), hash an empty string:

e3b0c44298fc1c149afbf4c8996fb92427ae41e4649b934ca495991b7852b855

Sign the exact string you send. If you serialize JSON, sign it and then send that same string. Re-serializing can change spacing or key order and break the signature.

Step 2: Build the string to sign

Join these five values with a newline (\n), with no trailing newline:

HTTP_METHOD        (uppercase, e.g. POST)
REQUEST_PATH       (path , e.g. /v2/topconnect/api/generate_checkout_hash)
TIMESTAMP          (same value as X-Timestamp)
NONCE              (same value as X-Nonce)
BODY_SHA256        (from Step 1)

Step 3: Sign it

signature = lowercase_hex( HMAC_SHA256( key = SECRET_KEY, message = string_to_sign ) )

Send the result in the X-Signature header.

---

Worked example

Use these values to test your implementation. If your code produces the same signature, it's correct.

Credentials (test only):

API Key:    ak_test_51HxQ2EXAMPLEKEY
Secret Key: sk_test_9fA3kL0EXAMPLESECRET

Example 1: POST with a body

Request:

POST /v1/orders
Body: {"amount": "100","invoice_number": "INVOICE1000",
  "notify_url": "https://google.io/"
}
Timestamp: 1760610000
Nonce:     7c2f9e1a4b8d3c6e5f0a1b2c3d4e5f60

Body SHA-256:

f0dddce8b8b9e1171674ba3f0b4d5421cf2439a6e5b8f818f898630c558882a3

String to sign:

POST
/v2/topconnect/api/generate_checkout_hash
1760610000
7c2f9e1a4b8d3c6e5f0a1b2c3d4e5f60
f0dddce8b8b9e1171674ba3f0b4d5421cf2439a6e5b8f818f898630c558882a3

Signature:

2b2b67508bb8a3e5bfffb9f88c41baee90430cc0089b1a65eafab0494f0f58c1

Full request:

curl -X POST "{{url}}/b2bapi/checkout_qr" \
  -H "Content-Type: application/json" \
  -H "X-API-Key: ak_test_51HxQ2EXAMPLEKEY" \
  -H "X-Timestamp: 1760610000" \
  -H "X-Nonce: 7c2f9e1a4b8d3c6e5f0a1b2c3d4e5f60" \
  -H "X-Signature: 2b2b67508bb8a3e5bfffb9f88c41baee90430cc0089b1a65eafab0494f0f58c1" \
  -d '{
 "amount": "100",
  "invoice_number": "INVOICE1000",
  "notify_url": "htttps://google.ph/return"
}
'

Code samples

Node.js

const crypto = require('crypto');

const API_KEY = process.env.API_KEY;
const SECRET_KEY = process.env.SECRET_KEY;
const BASE_URL = 'https://api.example.com';

async function apiRequest(method, path, bodyObj) {
  const body = bodyObj ? JSON.stringify(bodyObj) : '';
  const timestamp = Math.floor(Date.now() / 1000).toString();
  const nonce = crypto.randomBytes(16).toString('hex');
  const bodyHash = crypto.createHash('sha256').update(body).digest('hex');

  const stringToSign = [method.toUpperCase(), path, timestamp, nonce, bodyHash].join('\n');
  const signature = crypto.createHmac('sha256', SECRET_KEY).update(stringToSign).digest('hex');

  const res = await fetch(BASE_URL + path, {
    method,
    headers: {
      'Content-Type': 'application/json',
      'X-API-Key': API_KEY,
      'X-Timestamp': timestamp,
      'X-Nonce': nonce,
      'X-Signature': signature,
    },
    body: body || undefined,
  });
  return res.json();
}

// Usage
apiRequest('POST', '/v2/topconnect/api/generate_checkout_hash', { amount: 1500, currency: 'PESO' }).then(console.log);

Python

import hashlib, hmac, json, os, secrets, time
import requests

API_KEY = os.environ["API_KEY"]
SECRET_KEY = os.environ["SECRET_KEY"]
BASE_URL = "https://api.example.com"

def api_request(method, path, body_obj=None):
    body = json.dumps(body_obj, separators=(",", ":")) if body_obj else ""
    timestamp = str(int(time.time()))
    nonce = secrets.token_hex(16)
    body_hash = hashlib.sha256(body.encode()).hexdigest()

    string_to_sign = "\n".join([method.upper(), path, timestamp, nonce, body_hash])
    signature = hmac.new(SECRET_KEY.encode(), string_to_sign.encode(), hashlib.sha256).hexdigest()

    headers = {
        "Content-Type": "application/json",
        "X-API-Key": API_KEY,
        "X-Timestamp": timestamp,
        "X-Nonce": nonce,
        "X-Signature": signature,
    }
    return requests.request(method, BASE_URL + path, headers=headers, data=body or None).json()

# Usage
print(api_request("POST", "/v2/topconnect/api/generate_checkout_hash", {"amount": 1500, "currency": "PESO"}))

---

Rules enforced by the server

• Timestamp window: requests whose X-Timestamp differs from server time by more than 5 minutes are rejected. Keep your server clock synced (NTP).
• Nonce reuse: each nonce can be used only once per API key. A repeated nonce is rejected as a replay.
• Signature mismatch: any change to the method, path, query string, or body after signing invalidates the request.
• Rate limits: each API key is limited to N requests per minute. Exceeding it returns 429.

---

Error responses

All authentication errors return HTTP 401 (or 429 for rate limits) with a JSON body:

{
  "error": {
    "code": "invalid_signature",
    "message": "The request signature does not match."
  }
}

HTTP	code	Meaning	How to fix
401	missing_headers	One or more auth headers are missing	Send all four X- headers
401	invalid_api_key	API key not found or revoked	Check the key in your dashboard
401	timestamp_expired	Timestamp outside the 5-minute window	Use current Unix seconds; sync your clock
401	nonce_reused	Nonce was already used	Generate a new random nonce for every request
401	invalid_signature	Signature does not match	Compare your string-to-sign with the worked example
403	ip_not_allowed	Request came from an IP not on the key's allowlist	Add your server IP in the dashboard
403	insufficient_scope	Key doesn't have permission for this endpoint	Use a key with the required scope
429	rate_limited	Too many requests	Retry after the Retry-After header value

---

Troubleshooting invalid_signature

1. Body mismatch: you signed one JSON string but sent another (different spacing or key order). Sign and send the same string.
2. Path mismatch: the path must include the query string exactly as sent, and must not include the domain.
3. Newlines: use \n (LF), not \r\n, and no trailing newline.
4. Hex case: both the body hash and signature must be lowercase hex.
5. Wrong key: HMAC must use the Secret Key, not the API Key.
6. Run the worked example above through your code. If you don't get 2b2b6750...0f58c1, the bug is in your signing code.

---

Keeping your keys safe

• Store keys in environment variables or a secrets manager, never in source code or git.

• Never call this API directly from a browser or mobile app. Call it from your backend.

• Rotate your Secret Key from the dashboard if you suspect it has leaked. The old key keeps working for 24 hours so you can switch without downtime.

• Restrict each key to your server IPs and to only the scopes it needs.
